For instances where there is a significant difference in the outside diameter of pipes, VIPSeal® adaptor couplings are step moulded and fitted with two stainless steel tension bands providing a sealing solution that’s as quick to fit as it is robust.
VAR Adaptor Couplings
VIPSeal® VAR adaptor couplings incorporate an extra wide tension band at one end to allow a secure connection from clay pipe to structured twin wall or ribbed plastic pipe.
Adaptor Couplings Applications
- Connection of pipes with significantly different outside diameter
- Connection of lateral to unadopted sewers
- Connection of pipes to prefabricated structures e.g. manholes, inspection chambers and septic tanks
- Connection of clay pipes to structured/twin wall/ribbed plastic pipes
VAC Adaptor Couplings
| Ref No. | Size Range | Width |
|---|---|---|
| VAC0752 | 75-89 / 53-63mm | 90mm |
| VAC1001 | 100-115 / 40-50mm | 100mm |
| VAC1002 | 100-115 / 50-64mm | 100mm |
| VAC1003 | 100-115 / 75-90mm | 95mm |
| VAC1201 | 105-120 / 35-45mm | 100mm |
| VAC1225 | 110-122 / 48-56mm | 100mm |
| VAC1226 | 110-122 / 60-68mm | 120mm |
| VAC1221 | 110-122 / 80-95mm | 100mm |
| VAC5144 | 110-125 / 100-115mm | 100mm |
| VAC1361 | 121-136 / 80-95mm | 120mm |
| VAC4000 | 121-136 / 110-121mm | 100mm |
| VAC1362 | 121-136 / 100 -115mm | 100mm |
| VAC1452 | 130-145 / 110-125mm | 120mm |
| VAC1501 | 135-152 / 100-115mm | 120mm |
| VAC1552 | 140-155 / 90-105mm | 120mm |
| VAC1602 | 144-160 / 110-122mm | 120mm |
| VAC1603 | 144-160 / 121-136mm | 120mm |
| VAC1701 | 153-168 / 100-115mm | 150mm |
| VAC1702 | 155-170 / 100-115mm | 120mm |
| VAC1703 | 155-170 / 130-145mm | 120mm |
| VAC1801 | 160-180 / 100-115mm | 150mm |
| VAC1922 | 170-192 / 110-122mm | 120mm |
| VAC1923 | 170-192 / 121-136mm | 120mm |
| Ref No. | Size Range | Width |
|---|---|---|
| VAC1924 | 170-192 / 144-160mm | 120mm |
| VAC2000 | 180-200 / 130-145mm | 150mm |
| VAC2001 | 180-200 / 155-170mm | 150mm |
| VAC6000 | 180-200 / 160-180mm | 150mm |
| VAC2105 | 185-210 / 144-160mm | 150mm |
| VAC2101 | 185-216 / 160-180mm | 150mm |
| VAC2100 o/s | 185-212 / 100-115mm | 150mm |
| VAC2102 | 185-210 / 110-125mm | 150mm |
| VAC2152 | 195-215 / 100-115mm | 150mm |
| VAC2154 | 190-215 / 150-165mm | 150mm |
| VAC2203 | 195-220 / 155-170mm | 150mm |
| VAC2254 | 200-225 / 160-175mm | 150mm |
| VAC2352 | 210-235 / 110-122mm | 150mm |
| VAC2353 | 210-235 / 121-136mm | 150mm |
| VAC2354 | 210-235 / 144-160mm | 150mm |
| VAC2355 | 210-235 / 170-192mm | 150mm |
| VAC2356 | 210-235 / 170-192mm | 150mm |
| VAC2654 | 240-265 / 144-160mm | 150mm |
| VAC2655 | 240-265 / 170-192mm | 150mm |
| VAC2656 | 240-265 / 190-215mm | 150mm |
| VAC2657 | 240-265 / 210-235mm | 150mm |
| VAC2754 | 250-275 / 160-175mm | 150mm |
| VAC2756 | 250-275 / 200-225mm | 150mm |
| Ref No. | Size Range | Width |
|---|---|---|
| VAC2804 | 255-280 / 155-175mm | 150mm |
| VAC9001 | 260-285 / 180-205mm | 150mm |
| VAC2652 | 260-285 / 240-265mm | 150mm |
| VAC2904 | 265-290 / 144-160mm | 150mm |
| VAC2906 | 265-290 / 190-215mm | 150mm |
| VAC2907 | 265-290 / 210-235mm | 150mm |
| VAC2908 | 265-290 / 235-260mm | 150mm |
| VAC2956 o/s | 270-295 / 185-210mm | 150mm |
| VAC3003 o/s | 275-300 / 180-200mm | 150mm |
| VAC3204 | 295-320 / 144-160mm | 165mm |
| VAC3205 | 295-320 / 170-192mm | 150mm |
| VAC3207 | 295-320 / 210-235mm | 150mm |
| VAC3208 | 295-320 / 240-265mm | 150mm |
| VAC3209 | 295-320 / 265-290mm | 150mm |
| VAC3351 o/s | 310-335 / 180-205mm | 150mm |
| VAC3608 | 335-360 / 240-265mm | 165mm |
| VAC3609 | 335-360 / 265-290mm | 165mm |
| VAC3600 | 335-360 / 295-320mm | 165mm |
| VAC3858 | 360-385 / 240-265mm | 165mm |
| VAC3859 | 360-385 / 265-290mm | 165mm |
| VAC3850 | 360-385 / 300-325mm | 165mm |
| VAC4208 | 395-420 / 240-265mm | 165mm |
| VAC4209 | 395-420 / 265-290mm | 165mm |
VAR Adaptor Couplings
| Ref No. | Size Range | Width |
|---|---|---|
| VAR1500 | 160-170 / 170-192mm | 100mm |
| VAR2250 | 240-250 / 260-285mm | 130mm |
| VAR3000 | 325-335 / 360-385mm | 165mm |
o/s = offset
Also available with nitrile sleeves (add ‘N’ to the product code when enquiring or placing an order).
All of the above codes come complete with 304SS Tension Bands, for situations where there is a higher risk of corrosion or contaminated ground and marine enviorments, the above can be supplied with 316SS Tension bands (add ‘A’ to the product codes when enquiring or placing an order).
