Primarily used in sewers, drains and other low and non-pressurised applications, VIPSeal® VSC Standard Couplings join pipes of virtually any material or diameter.
Constructed from the highest quality elastomeric rubber (EPDM), the VSC Standard Couplings create a leak proof seal. In addition, the couplings are bolstered by stainless steel shear bands, proving shear resistance under heavy earth loads.
All VSC Standard Couplings Comply With The Following
- BS EN295-4
- WIS 4-41-01
- DIBT/MPA (Germany)
- VA (Scandinavia)
- WSAA – AS/NZS 4327 (Australasia)
- BS EN16397
All our VSC Standard Couplings come with same day or next day delivery.
VSC Standard couplings applications:
- As a coupling to join plain ended pipes
- Repair damaged sections of pipes
- Where a post or lateral connection is required
- Where the diameters of pipe differ
- Joining short and cut lengths of pipe
- Introducing rocker pipes to an outside structure or manhole
| Ref No. | Size Range | Width |
|---|---|---|
| VSC65 | 50-65mm | 90mm |
| VSC75 | 65-75mm | 108mm |
| VSC95 | 80-95mm | 100mm |
| VSC100 | 85-100mm | 80mm |
| VSC115 | 100-115mm | 120mm |
| VSC120 | 110-121mm | 120mm |
| VSC125 | 110-125mm | 120mm |
| VSC137 | 120-137mm | 120mm |
| VSC150 | 125-150mm | 120mm |
| VSC165 | 140-165mm | 120mm |
| VSC175 | 150-175mm | 120mm |
| VSC180 | 160-180mm | 120mm |
| VSC200 | 175-200mm | 150mm |
| VSC215 | 190-215mm | 150mm |
| VSC225 | 200-225mm | 150mm |
| VSC250 | 225-250mm | 150mm |
| VSC265 | 240-265mm | 150mm |
| VSC275 | 250-275mm | 150mm |
| VSC290 | 265-290mm | 150mm |
| VSC310 | 285-310mm | 190mm |
| VSC320 | 295-320mm | 190mm |
| Ref No. | Size Range | Width |
|---|---|---|
| VSC335 | 305-335mm | 190mm |
| VSC345 | 315-345mm | 190mm |
| VSC360 | 340-360mm | 190mm |
| VCS365 | 345-365mm | 190mm |
| VSC385 | 355-385mm | 190mm |
| VSC410 | 385-410mm | 190mm |
| VSC425 | 400-425mm | 190mm |
| VSC430 | 405-430mm | 190mm |
| VSC445 | 420-445mm | 190mm |
| VSC465 | 435-465mm | 190mm |
| VSC470 | 440-470mm | 190mm |
| VSC490 | 465-490mm | 190mm |
| VSC510 | 480-510mm | 190mm |
| VSC525 | 495-525mm | 190mm |
| VSC540 | 510-540mm | 190mm |
| VSC550 | 520-550mm | 190mm |
| VSC560 | 530-560mm | 190mm |
| VSC570 | 540-570mm | 190mm |
| VSC580 | 555-580mm | 190mm |
| VSC600 | 570-600mm | 190mm |
| VSC620 | 590-620mm | 190mm |
Also available with nitrile sleeves (add ‘N’ to the product code when enquiring or placing an order).
All of the above codes come complete with 304SS Tension Bands, for situations where there is a higher risk of corrosion or contaminated ground and marine enviorments, the above can be supplied with 316SS Tension bands (add ‘A’ to the product codes when enquiring or placing an order).
